| SPECIFICATION 1450 | |||||||||||||||||||||||
| Designed for H2O Heating Services Ltd. | |||||||||||||||||||||||
 Heat Bank Thermal Store Thermal
Store Everest Type with
Integral F&E Tank Electric 3
kW Incaloy Heater Blanked Heater
Boss Heat Exchanger Controls Thermostatic Blending
Valve Ball Valve with Mains
Feed Radiator Circuit Pump Cylinder
Thermostat Junction Box
|
| ||||||||||||||||||||||
 The
connection to the ball valve is made using a flexible filling loop.
This may be left connected during operation to provide automatic
re-filling via the ball valve. An overflow will be required.
Alternatively, the filling loop may be disconnected during operation, with
the unit manually re-filled. In this type of installation, no
overflow is required.
| |||||||||||||||||||||||
